MADE IN USA
BOLT ON IFS KIT : COILOVER VERSION
APPLICATION:
60-62 GM TRUCK 1/2 & 3/4 TON ONLY
LEAD TIMES 2-3 WEEKS
INCLUDED:
CROSS MEMBER (BOLT ON)
UPPER CONTROL ARM AND COILOVER MOUNT (BOLT ON)
UPPER AND LOWER CONTROL ARMS (BOLT ON)
INSIDE FRAME AND ENGINE MOUNT SUPPORT (BOLT ON)
ENGINE MOUNTS (BOLT ON)
RACK AND PINION FRONT PLATE
GRADE 8 HARDWARE & POLYURATHANE BUSHINGS
ADD ONS:
UPPER AND LOWER BALL JOINTS
RE-MANUFACTURED RACK AND PINION (RECOMMENDED) - 1 YR WARRANTY
TIE ROD KIT: MACHINED ADJUSTMENT SLEEVE, SPACERS, SPINDLE INSERT, HEIM JOINT
ALDAN AMERICAN SINGLE ADJUSTMENT COILOVERS - LIFETIME WARRANTY
ECONOMY DISC BRAKE KIT: 5 LUG (GM 5 ON 5), 2.5" DROP SPINDLE, 11" ROTORS PLAIN, DUAL PISTON CALIPERS, BRAKE LINES, SEALS AND BEARINGS.
CPP DISC BRAKE KIT: 5 LUG (GM 5 ON 5), 2.5" MODULAR DROP SPINDLE, 12" ROTORS PLAIN, DUAL PISTON CALIPERS, BRAKE LINES, SEALS AND BEARINGS.
PART#
1963-70 : 6370SWBK-05 (5 LUG, 5X5.5 PATTERN), 6370SWBK-06 (6 LUG, 6X5.5 PATTERN)
1971-72 : 7172SWBK-05 (5 LUG, 5X5.5 PATTERN), 7172SWBK-06 (6 LUG, 6X5.5 PATTERN)
1973-87 : 7387SWBK-05 (5 LUG, 5X5.5 PATTERN), 7387SWBK-06 (6 LUG, 6X5.5 PATTERN)
WILWOOD DISC BRAKE KIT: 5 OR 6 LUG AVAILABLE, 2.5" MODULAR WILWOOD PRO SPINDLE, 12.19" ROTORS (DRILLED AND SLOTTED), FORGED NARROW SUPERLITE 6 PISTON BIG BRAKE KIT(RED OR BLACK CALIPER OPTION)
1963-70: PRO SPINDLE 831-15931 1971-87 : PRO SPINDLE 831-15932
BRAKE KIT (5 LUG, 5X5.5 PATTERN): BLACK CALIPER 140-15940-D, RED CALIPER 140-15940-DR
BRAKE KIT (6 LUG, 6X5.5 PATTERN): BLACK CALIPER 140-15944-D, RED CALIPER 140-15944-DR
TRANSMISSION MOUNT: UNIVERSAL FOR ANY GM TRANSMISSION
SHIPPING:
FRONT AND REAR CLIPS ARE PICK UP OR LOCAL DELIVERY ONLY TO GET ONE SHIPPED NATIONALLY PLEASE PLACE ORDER AND GIVE US A CALL
PART NUMBER: AMS-IFSKC6062
